SC Error Codes
J012/J013/J014 4-34 SM
Jam 11 Duplex Paper Jam Between TE Sensor and Registration Sensors
Message: Paper Misfeed: Inverter Guide Plate
Jam
A paper late jam occurred while printing the 2nd side of a duplex print or
inverting paper. The trailing edge sensor detected the leading and trailing
edge of the paper but the registration sensors failed to detect the paper
because it stopped. (The registration sensor did, however, detect the
leading edge of the inverted paper from the duplex unit.)
Cause: The registration sensors failed to signal detection of the paper.
Problem Site
Trailing edge sensor
1st Registration sensor
2nd Registration sensor
CTL board
Action
Perform check, take action in this order:
1. Replace the inverter guide plate.
2. Replace the trailing edge sensor.
3. Replace 1st, 2nd Registration sensors.
4. Replace the CTL board.
