Technical Bulletin PAGE: 3/9
Model: Taurus-C1/P1 (D074/D075/M044)
Date: 20-Jul-12
No.: RD074081
Replacement Procedure
1. Clear the skew motor adjustment values by executing the following SP(s). Clear only
the values of the stations that require the replacement of the skew motor.
SP2104-31 Clear Revision C (for Cyan)
SP2104-32 Clear Revision M (for Magenta)
SP2104-33 Clear Revision Y (for Yellow)
2. Remove the laser unit from the mainframe. (See section “4.Replacement and
Adjustments > Laser Unit > Laser Units” of the field service manual).
[A]
