374
Programming cable
PC cable, (RS232 or USB)
Third party device(HMI)
<=> xLogic
Yes (work as modbus master or slave)
Extensions
No
High speed input
No
I5---I8(60kHz)
HMI
Yes
RS485 port
Option1:Can use PRO-RS485 cable to convert program port to RS485 port
Standard CPU Units
(PR-18 series)
PR-14AC-R
PR-14DC-DA-R
Power supply:
Nominal voltage
AC110V-240V
DC 12-24V
Operating limits
AC85 - 265 V
DC 10.8-28.8V
Immunity from micro
power cuts
---
Typ. 5 ms
Max. Startup current
---
Max. 0.25A
Max. absorbed power
49mA (85V ac) ;
37mA (265V ac)
3.5 W (10.8V dc) ;
4 W (28.8V dc)
Protection against polarity
inversions
Yes
Yes
The main frequency range
47-63Hz
---
Input parameters:
Input No
10 ( I1-IA )
10 (I1-IA )
Digital input
10 ( I1-IA )
10 (I1-IA )
Analogue input
None
6 ( I1-I6)(0..10V DC)
Input voltage
AC0-240V
DC 0-28.8V
Input signal0
AC0-40V；<0.03mA
< 5V DC;<0.1mA(I1-I6),<1mA(I7-IC)
Input signal1
AC79-240V；
>0.06mA
> 8 V DC;>0.3mA(I1-I6),>1.7mA(I7-IC)
Input current
---
0.4mA(I1-I6),2.3mA(I7-IC),@ 10.8V dc
0.5mA(I1-I6),2.6mA(I7-IC),@ 12.0 V dc
1.2mA(I1-I6),5.2mA(I7-IC),@ 24 V dc
1.5mA(I1-I6),6.3mA(I7-IC),@ 28.8 V dc
Input Response Time
Delay time at 0 to 1：
120V AC ：Typ. 50 ms
240V AC ：Typ. 30 ms
Delay time at 1 to 0：
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Delay time at 0 to 1 ：
Typ. 1.5 ms (I1-I6),<1ms(I7-IC)；
Delay time at 1 to 0 ：
Typ. 1.5 ms(I1-I6),<1ms(I7-IC)；
Maximum counting
frequency
Typ. 4Hz
Typ.：4 HZ
Sensor type
Contact or 3-wire PNP
Contact or 3-wire PNP
Isolation between power
supply and inputs
None
Resistive
