8.2 Technical data - Multilift II
Multilift II
Standard/ESD/Clean
Multilift II
impact
Multilift II
telescope/telescope ESD
Base area [mm] (L
x B)
312 x 90 328 x 90
Height [mm] Stroke + 203 Stroke
+ 209
560
Stroke [mm] 355, 400, 452, 498 650
Weight [kg] 4.89 + (0.016 kg/mm) x stroke 15
Supply voltage [V
DC]
28
Protection class III
Electrical connec-
tion
8-pin Mini-Fit Jr. plug connector
Current consump-
tion, max. [A]
4.5
Power input, max.
[W]
120
Duty cycle (DC)
with nominal load
DC 10% at 20 minutes:
n 2 minutes movement
n 18 minutes standby
Service life
n 10 000 double strokes with stroke 500 mm, 1000 N, 16 mm/s
n 5 000 double strokes with stroke 500 mm, 3000 N, 8 mm/s
Protection rating IP 20 IP 30
Continuous sound
pressure level
[dBA]
< 60
Lifting speed
[mm/s]
8 16 8 8 16
Compressive
force/tensile force,
max. [N]
3000/3000 1000/1000 3000/3000 3000/2000 1000/1000
Ä
“Maximum compressive/tensile force
depending on the stroke length”
on page 117
Ä
“Maximum compressive/tensile force
depending on the stroke length”
on page 118
Compressive
force/tensile force,
max. [N]
(in medical applica-
tions)
2500/500 1000/500 2500/500 1500/500 1000/500
Ä
“Maximum compressive/tensile force
depending on the stroke length in medical
applications” on page 118
Ä
“Maximum compressive/tensile force
depending on the stroke length in med-
ical applications” on page 119
Position signal
(Pulses per mm of
travel distance)
13 6.5 6.5 13 6.5
Technical data
Technical data - Multilift II
20.02.2019 Lifting column Multilift I/Multilift II 115
