8.4.2 Maximum torque values - Multilift II
Maximum torque values with load via the ...
... long side ... short side
Views
Multilift II Standard/ESD/clean
n 200 Nm (dynamic)
n 300 Nm (static)
n 130 Nm (dynamic)
n 200 Nm (static)
Multilift II impact
n 200 Nm (dynamic)
n 300 Nm (static)
n 130 Nm (dynamic)
n 200 Nm (static)
Multilift II telescope/telescope
ESD
n 200 Nm (dynamic)
n 300 Nm (static)
n 100 Nm (dynamic)
n 200 Nm (static)
8.5 Rating plate
The rating plate (Fig. 39) is located on the motor housing.
1 Sales number
2 Customer item number
3 Serial number
4 Voltage, max. current consumption, travel speed
5 Max. tensile/compressive load
6 Duty cycle
7 Caution! Danger!
8 Do not dispose of with household waste!
9 CE marking
10 Only use in closed rooms!
11 Observe the instructions!
12 Year of manufacture
13 Type designation
Fig. 39: Rating plate
Technical data
Rating plate
