Further information:
n Assembling the internal profile Ä page 104
n Assembling the external profile
Ä page 106
Fig. 14: Overview of interfaces/connection points - Multilift II telescope/telescope ESD
A Top view
B View with base plate
C View with top assembly plate
Further information:
n Assembling the internal profile Ä page 104
n Assembling the external profile
Ä page 106
3.5 Electrical connection to a controller provided by the operator
Adhere to this chapter if the lifting column is operated
using the operator's own controller.
If using a controller not listed in Ä Chapter 3.3.6 “Con-
troller” on page 91, adhere to the valid directives and
standards.
Multilift II telescope/telescope ESD
Set-up and function
Electrical connection to a controller provided by the operator
20.02.2019Lifting column Multilift I/Multilift II94
