45Overview of the system
Roche Diagnostics
cobas
®
pulse · Software version 01.03 · User Assistance · Publication version 1.0
The button provides access to the results that are
currently stored on the instrument
• Patient results
• QC results
The button provides access to the Notifications
screen which is used for the following:
• Reminders (for example, QC test is due)
• Messages (for example, message of the day, personal
messages)
• Logging cleaning
A blue notification badge on the button ( ) indicates
that notifications require a response from you. After you
have responded, the blue badge disappears.
The button provides access to the Settings screen
which contains options to manage different aspects of
your instrument (for example, setting the date and time,
brightness and volume).
u List of notifications (72)
About the charging screen
The charging screen is displayed when the instrument is
docked in the charging station.
QC lockout
Synchronization lockout
Location
Site
Instrument name / ID
It contains the following information:
• Battery level of the instrument.
• Lockout notifications if applicable (2 items maximum).
• Instrument name and/or ID if configured (top of
screen).
• Site and location where the instrument is used if
configured (bottom of screen).
The battery level is indicated by a percentage value and a
color coded battery indicator. The color coding is
determined as follows:
• Red = 15% and below
• Yellow =16% to 89%
• Green = 90% and above
The battery indicator color corresponds with the
instrument’s charge indicator color.
2 Overview of the system
