5–53Part Replacement Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Installation
Refer to Fastener Torque Specifications in Chapter 3, Access
Procedures.
1. Apply a thin, even coat of Penatrox or equivalent (not supplied)
to the base of the new diode.
2. Position the new Converter Diode. Be careful to match the holes
for the screws.
3. Tighten the four screws.
4. Bolt down the L-shaped bus bar with two bolts.
5. Bolt down the two bus bars with six bolts.
6. If not connected, connect the Flex bus.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
