Rockwell Automation Allen-Bradley IMPACT 1336 Series

7–13Schematics
Publication 1336 IMPACT-6.8 – November, 2002
Based on the maximum drive rating the following fuses, or approved
equivalents, must be used for the AC input power.
Table 7.A
AC Input Power, Converter Bay Fuses (F1 – F3 and F1A – F3A)
Horsepower
AC Input Voltage Fuse Type
700 and 800 480 and 575 SPP-6K700 Bussman
Based on the drive horsepower, the following fuses, or approved
equivalents, must be used for the Inverter DC+ Bus.
Table 7.B
Inverter DC+ Bus Fuses (F1 – F3)
Horsepower/
Input olta e
Fuse Information
orsepower/
Input Voltage
Rating
Type P/N
ALL SIZES 300A A7OQ 25178-310-14
Table 7.C lists fuse data for all printed circuit assemblies.
Table 7.C
Printed Circuit Fuses
Item
/M
Schematic
a ram
Fuse Information
Item
B
/M
Schemat c
Diagram
Designator Rating Type P/N
A
1
Bo
74101
-
163
-XX
74101
-
167
F1 1.0 A/600 V KTK-R 25172-260-08
Gate Driver
Bo
ard
F3 1.5 A/600 V KTK-R 25172-260-09
Fuse Tables
