Rockwell Automation Publication 2198-RM002A-EN-P - October 2017 63
System Replacement Examples Chapter 3
Circuit Protection
For this example application, the following fuse and circuit breaker options
apply when the motion system is a UL/CSA application.
Refer to Circuit Breaker and Fuse Considerations
on page 35 for fuse and
circuit breaker recommendations for all Kinetix 6000 IAM modules and
Kinetix 5700 DC-bus power supplies.
Table 28 - Control and DC-Bus Circuit Protection Specifications
Contactor Specifications
The DC-bus power supply contactor enable relay (CED connector) is rated at
24V DC or 110/220V AC at 1.0 A, max.
Table 29 - Contactor Specifications
AC Line Filter Specifications
These AC line filters are available for your servo drive input power.
Table 30 - AC Line Filter Specifications
Drive Cat. No.
Control Input Power DC-bus Power
Bussmann Fuse
(1)
Bussmann Fuse Mersen Fuse
(2)
Miniature CB Molded Case CB
2094-BC07-M05-S
FNQ-R-10 (10 A) or
FNQ-R-7.5 (7.5 A)
FWJ-125A A70QS125-4 or HSJ125 – 140G-G6C3-C90
2198-P208 – LPJ-100SP (100A) – – 140G-G6C3-D12
(1) Use FNQ-R-7.5 circuit breaker for higher single-cycle inrush current capability. This is recommended when the continuous control-power current exceeds 3.0 A.
(2) Mersen fuses were formerly known as Ferraz-Shawmut.
Drive Cat. No. Contactor Intermediate Relay
2094-BC07-M05-S
FNQ-R-10 (10 A) or
FNQ-R-7.5 (7.5 A)
FWJ-125A
2198-P208 100-C97DJ10
700-HB32Z24 (relay)
700-HN153 (socket)
Drive Cat. No. AC Line Filter Cat. No.
2094-BC07-M05-S 2090-XXLF-3100
2198-P208 2198-DB80-F
