8 Rockwell Automation Publication 2198-RM002A-EN-P - October 2017
Preface
Kinetix 5700 Drive Module Components
Kinetix 5700 servo drive systems consist of these required components:
• 2198-Pxxx DC-bus power supplies (up to three modules that are wired
in parallel are possible)
• Single-axis and dual-axis inverters
– Extended drive systems are possible with Bulletin 2198 capacitor
modules
• Kinetix VP (400V-class) servo motors
– Use 2090-CSxM1DE cables (includes 2198-KITCON-DSL
feedback connector kit)
– Use 2090-CSxM1DG flying-lead cables (order 2198-KITCON-
DSL connector kit separately)
• MP-Series™ (400V-class) servo motors and actuators, LDAT-Series
linear thrusters, LDC-Series™ linear motors, or HPK-Series™
asynchronous rotary motors
– Use 2090-CPxM7DF power/brake cables
– Use 2090-CFBM7DF feedback cables and many legacy-motor
feedback cables with 2198-K57CK-D15M universal feedback
connector kits
• Support for induction motors with basic volts/hertz, fan/pump V/Hz,
and sensorless-vector open-loop frequency control methods or closed-
loop motor feedback options
• 1606-XLxxx 24V power supplies for control and motor brake power
• 1585J-M8CBJM-x (shielded) Ethernet cable
Kinetix 5700 servo drive systems can also include any of these optional
components:
• 2198-CAPMOD-2240 capacitor modules
• 2198-CAPMOD-DCBUS-IO extension modules
• 2198-ABQE encoder output module
• One 2198-DBxx-F AC line filter
• 2198-Rxxx external passive-shunt resistors
• Bulletin 1321 line reactors
(required with two or three 2198-P208 DC-bus power supplies)
• Bulletin 2198 24V DC input power shared-bus connection system
For detailed Kinetix 5700 drive system requirements, refer to the Kinetix 5700
Drive Systems Design Guide, publication KNX-RM010
.
