Kinetix 5700 Drive Modules
Module
Cat. No.
Module Width
mm
Input Voltage
Continuous Output
Power
kW
Continuous Output
Current to Bus
A
DC
rms
Continuous Output
Current
A 0-pk
DC-bus Power Supply
2198-P031
2198-P070
55
324…528V AC rms,
three-phase
7
17
10.5
25.5
–
2198-P141
2198-P208
85
31
46
46.9
69.2
Dual-axis Inverters
2198-D006-ERS3
2198-D012-ERS3
2198-D020-ERS3
2198-D032-ERS3
55
–
1.7
3.4
5.5
8.9
–
3.5
7.0
11.3
18.3
2198-D057-ERS3 85 15.9 32.5
Single-axis Inverters
2198-S086-ERS3
2198-S130-ERS3
85
–
29.7
44.9
60.8
91.9
2198-S160-ERS3 100 60.1 120.2
