Rockwell Automation Publication 750-TG100B-EN-P - June 2019 161

Control Bay and Control Pod Components Chapter 7

19. Loosen the three captive thumb screws that secure the main control board

to the pod chassis and remove the board.

–

T15 or F - 5 mm (0.19 in.)

0.45 N•m (4 lb•in)

HIM Bezel Not Shown for Clarity Only.
