Indication in the display:
Display Icon Description Remark
PAUS
 While paused, the kiln
temperature display
will alternate periodically with a
scrolling “PAUSED” display
 and a beep will be sounded.
 Program execution is suspended, and the
kiln will be held at its current temperature.
 The pause will come to an end
automatically after a preset period.
 The pause function is preset to 2 hours at
the factory.
8.2. Notes on the firing process
8.2.1. Querying kiln performance
• The controller operates by calculating the amount of energy required by the kiln every 30 seconds (installer
adjustable).
 The benefit for the user is that the power consumed is displayed at the end of the firing.
 Before the controller can display the required amount of energy in kilowatts, parameter no. 14 (see Section 12.)
must be set with the kiln performance.
 The consumption values can only be called up during firing or at the end of the firing curve. If the controller is
switched off or a new program is started, the consumption values are deleted.
 To check the required amount of energy in kilowatts (consumption values):
Press the h key (a small “i” is shown next to this arrow key).
• If for example 40% of full energy is required to maintain a particular ramp rate or a particular soak temperature
then the controller will apply heating power to the kiln for 12 seconds every 30 seconds.
• The kiln heating indicator will light for 12 seconds every 30 seconds.
• If the kiln has a contactor, then a loud click will be heard both when the kiln heating indicator lights up and when
it goes out. If full heating power is required, then the kiln heating indicator will remain lit. If full cooling is required,
the kiln heating indicator will remain off.
8.2.2. Cooling
Upon completion of firing the controller lights all LEDs on the graphical display. The kiln is switched
off and begins to cool down on its own.
Displays during the cooling phase:
Display 1 Icon 1 Display 2 Icon 2 Description
411 HOt
As long as the kiln temperature is above 40°C, the display
alternates between display 1 & 2 every 5 seconds.
39 En d
 As soon as the kiln has cooled down below 40°C, the display
alternates between display 1 & 2 every 5 seconds.
 The firing program runs until “END” is displayed.
 To switch the controller back to idle condition, press the
j key. It can now be switched off.
