66 / 291 - EN -
9.5. Firing program errors
Display Description Cause of error / Troubleshooting
Err. P
Program error:
This error message is displayed if a potential
error is detected within the firing program
when the
j
key is pressed to start a firing.
A buzzer sounds three times and the segment
number at which an error may have occurred
appears on the segment display.
Press the
g
key and the error message will
be deleted.
The controller now changes to programming
mode.
The program in which the error may have
occurred can be called up and changed if
necessary.
If no fault is found, then press the
j
key
again to force the firing program to start.
10. Interfaces
10.1. USB interface
10.1.1.
General description
The interface enables a USB flash drive to be connected to the controller. This is mainly used to generate files with
a timestamp and to store them on a computer for data logging. Data acquisition via USB is mainly used with
ROHDEgraph (see Section 10.3.). It can also read configuration and user-program data files into the controller.
10.1.2.
Interface properties
General safety note:
PROHIBITION
Do not connect any other devices, except a USB flash drive, to this USB interface.
No devices such as cell phones or laptops may be plugged into this USB interface to
charge the battery.
Description:
USB versions 1.0 or 2.0 are suitable for recording the measured values.
USB 3.0 is not compatible.
The USB flash drive must be formatted to FAT32 or FAT16.
NTFS format is not suitable.
The data logger module has been tested with common USB flash drives of 8, 16 and 32 GB.
The “USB flash drive plugged into USB port” indicator on the top of the housing confirms connection with a
compatible USB flash drive.
