68 / 291 - EN -
Step Display Segment display Description Remark
5
21.01 01
Move onto the next digit with the
g
key.
The last numerical value for the
day of the current date is in the
segment display.
6
21.01 01
Move to “Time” setting mode by
pressing the
g
key from the
flashing day display.
7
01.01 01
Navigate to the flashing digit with
the
g
or
h
key.
The time is now shown in
HH.MM.SS format.
8
01.01 01
Navigate to the flashing digit with
the
g
or
h
key.
After the call-up, the numerical
value for the hour flashes first.
9
01.01 01
Use the
d
and
f
keys to change
the flashing number.
10
01.01 01
Move onto the next digit with the
g
key.
The last numerical value for the
second of the current time is in
the segment display.
11
01.01 01
To exit Settings:
Press the
g
key while the
seconds display is flashing to
exit “Time” setting mode.
Or wait 15 seconds.
10.1.7.
Data logging
Data logging commences when a firing is started.
It finishes when the firing is complete and when the kiln has cooled to 100°C.
The “LOGxyz.CSV” file is generated on the USB flash drive.
The first file created will be “LOG000.CSV”.
Subsequent firing processes will generate files “LOG001.CSV” to “LOG999.CSV”.
Only 1000 log files in total can be created on the USB flash drive.
It is recommended that you move the log files to another storage medium after a few firing processes.
It takes about 1 second until the individual files are indexed on the flash drive and only then can a new file be
created.
So, for example, if there are files LOG000.CSV to LOG100.CSV on the USB flash drive there would be a delay of
just over 100 seconds before LOG101.CSV could be created and logging could be commenced.
The files are generated in CSV file format and ASCII code and can be imported directly into Microsoft Excel
tables.
10.1.8.
Logging interval
The interval can be set in configuration mode with parameter P50 in a range between 5 and 300 seconds
(see Section 12.).
Preset value:
60 seconds
