Cleaning
Edition BE210202
03.2022
Rondostar 5000
Operating manual
112
6.1.1.1 Machine body and substructure
• Damp clean the machine body and substructure weekly with a
brush / cloth and soapy water.
Also see 3.3 Full view of the machine
6.1.1.2 Safety guards
• Damp clean the safety guards weekly with a brush / cloth and
soapy water.
6.1.1.3 Light barrier / sensor wiper
Never clean the light barrier / sensor wiper when the machine is
running!
• Dry clean the light barrier / sensor weekly with a brush.
The light barrier (1) installed in the machine is cleaned automatically
with the light barrier cleaning mechanism (2).
If the conveyor belts on the machine only run in one direction, i.e.
non-reversing, while the automatic flour duster is in operation at the
same time, an undesired flour accumulation will result (scraper/belt),
which can lead to problems with the light barrier function.
1. Remove occasional flour accumulations manually.
1
2
