Installation manual
39
RKHBH/X008BB
Indoor unit for air to water heat pump system
4PW62574-1 – 10.2010
5 Equilibrium temperature and space heating priority temperature
00 Equilibrium temperature status (only in combination
with domestic hot water tank without electrical
booster heater (RKHTS), [4-03]=5, this setting is
fixed and can not be consulted)
1 (ON) — — —
00 Equilibrium temperature status (only in combination
with domestic hot water tank with built-in electrical
booster heater (RKHW*), [4-03]≠5)
1 (ON) 0/1 — —
01 Equilibrium temperature
0 –15~35 1 °C
02 Space heating priority status (only in combination
with domestic hot water tank without electrical
booster heater (RKHTS), [4-03]=5, this setting is
fixed and can not be consulted)
1 (ON) — — —
02 Space heating priority status (only in combination
with domestic hot water tank with built-in electrical
booster heater (RKHW*), [4-03]≠5)
0 (OFF) 0/1 — —
03 Space heating priority temperature
0 –15~35 1 °C
04 Set point correction for domestic hot water
temperature (only in combination with domestic hot
water tank with built-in electrical booster heater
(RKHW*), [4-03]≠5)
10 0~20 1 °C
6 DT for heat pump domestic water heating mode
00 Start 2 2~20 1 °C
01 Stop 2 0~10 1 °C
Scheduled storage and reheat domestic water heating
(a)
03 Scheduled time storage 1 (ON) 0/1 1 —
04 Scheduled time storage start time 1:00 0:00~23:00 1:00 hour
05 Scheduled time reheat or continuous reheat 0 (OFF) 0/1/2 1 —
06 Scheduled time reheat start time 15:00 0:00~23:00 1:00 hour
07 Domestic hot water reheat set point 45 30~50 1 °C
08 Domestic hot water reheat set point hysteresis 10 2~20 1 °C
7 DT for booster heater and dual set point control
00 Domestic hot water step length (only in combination
with domestic hot water tank with built-in electrical
booster heater (RKHW*), [4-03]≠5)
0 0~4 1 °C
01 Hysteresis value booster heater (only in
combination with domestic hot water tank with built-
in electrical booster heater (RKHW*), [4-03]≠5)
2 2~40 1 °C
02 Dual set point control status 0 (OFF) 0/1 — —
03 Second set point heating 10 1~24 / 25~55 1 °C
04 Second set point cooling 7 5~22 1 °C
8 Domestic water heating mode timer
00 Minimum running time 5 0~20 1 min
01 Maximum running time 30 5~95 5 min
02 Anti-recycling time (only in combination with
domestic hot water tank without electrical booster
heater (RKHTS), [4-03]=5)
0.5 0~10 0.5 hour
02 Anti-recycling time (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*), [4-03]≠5)
3 0~10 0.5 hour
03 Booster heater delay time (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*), [4-03]≠5)
50 20~95 5 min
04 Additional running time at [4-02]/[F-01] 95 0~95 5 min
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
