Rotex RKHBH008BB3V3 User Manual

RKHBH/X008BB
Indoor unit for air to water heat pump system
4PW62574-1 – 10.2010
Installation manual
38
8.10. Field settings table
First
code
Second
code Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
0 User permission level
00 User permission level 3 2/3 1 —
1 Weather dependent set point
00 Low ambient temperature (Lo_A) –10 –20~5 1 °C
01 High ambient temperature (Hi_A) 15 10~20 1 °C
02 Set point at low ambient temperature (Lo_Ti) 40 25~55 1 °C
03 Set point at high ambient temperature (Hi_Ti) 25 25~55 1 °C
05 Weather dependent for cooling function
enable/disable
0 (OFF) 0/1 — —
06 Low ambient temperature (Lo2_A) 20 10~25 1 °C
07 High ambient temperature (Hi2_A) 35 25~43 1 °C
08 Set point at low ambient temperature (Lo2_Ti) 22 5~22 1 °C
09 Set point at high ambient temperature (Hi2_Ti) 18 5~22 1 °C
2 Disinfection function
00 Operation interval Fri Mon~Sun, All — —
01 Status 1 (ON) 0/1 — —
02 Start time 23:00 0:00~23:00 1:00 hour
03 Set point (only in combination with domestic hot
water tank without electrical booster heater
(RKHTS), [4-03]=5)
60 fixed 5 °C
03 Set point (only in combination with domestic hot
water tank with built-in electrical booster heater
(RKHW*), [4-03]≠5)
70 55~80 5 °C
04 Interval (only in combination with domestic hot
water tank without electrical booster heater
(RKHTS), [4-03]=5)
60 40~60 5 min
04 Interval (only in combination with domestic hot
water tank with built-in electrical booster heater
(RKHW*), [4-03]≠5)
10 5~60 5 min
3 Auto restart
00 Status 0 (ON) 0/1 — —
4 Backup/booster heater operation and space heating off temperature
00 Backup heater operation (only in combination with
domestic hot water tank without electrical booster
heater (RKHTS)
1 (ON) 0/1/2 — —
00 Backup heater operation (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*))
1 (ON) 0/1 — —
01 Backup/booster heater priority 0 (OFF) 0/1/2 — —
02 Space heating off temperature 25 14~25 1 °C
03 Booster heater operation (only in combination with
domestic hot water tank without electrical booster
heater (RKHTS))
5fixed——
03 Booster heater operation (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*))
3 0/1/2/3/4 — —
04 Not applicable. ————
05 Not applicable. ————
06 Backup heater emergency operation 1
(enabled) 0/1 1 —
07 Backup heater second step 1
(enabled) 0/1 1 —
