Installation manual
41
RKHBH/X008BB
Indoor unit for air to water heat pump system
4PW62574-1 – 10.2010
F Option setup
00 Pump operation stop 0
(enabled)
0/1 1 —
01 Space cooling permission temperature 20 10~35 1 °C
02 Bottom plate heater ON temperature 3 3~10 1 °C
03 Bottom plate heater hysteresis 5 2~5 1 °C
04 Functionality of X14A
(b)
. 1 0/1 — —
Underfloor heating screed dry-out program
05 Action number selection 1 1~20 1 —
06 Heating set point of selected action number [F-05] 25.0
(c)
15~55 1 °C
07 Time of selected action number [F-05] 0
(c)
0~72 12 hour
08 Underfloor heating screed dry-out program enabled/
disabled
0 (OFF) 0/1 1 —
09 Latest action number executed
0
0~21
(Read only)
0—
(a) The storage and reheat function is only applicable in case [4-03]=4 or 5.
(b) Only possible to modify the first 3 minutes after power ON.
(c) For all action numbers of [F-05].
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
