SAMSUNG Programming
DCS-816 February, 1999
MMC 403 (Page 2 of 2)
4. Enter night toll class (e.g., 2)
OR
Press UP or DOWN to scroll through toll
classes and press RIGHT soft key to return to
step 2
[704] TOLL CLASS
D:CLS–B N:CLS–B
5. Press TRSF to store data and exit
OR
Press SPK to store data and advance to next
MMC
DEFAULT DATA: All trunks F–STN day/night
RELATED ITEMS: MMC 301 Assign Station COS
MMC 507 Assign Auto Night Time
MMC 701 Assign COS Contents
Toll Restriction
