Tunable Semiconductor Laser TSL- 710
5-11
Sweep Setting (2/2)
Setting items on the second page depends on which mode was selected on the rst page.
〈
If Step mode is selected:
〉
Step
Sets the wavelength interval of the step
Range: 0.0001 to 160.000 nm
Unit: 0.0001 nm
Dwell
Sets the amount of time spent for each step
Range: 0.0 to 999.9 s
Unit: 0.1 s
Cycles
Sets the number of times the sweep is repeated
Range: 0 to 999 times
Unit: 1
If the value is set to 0 (zero), the number of times is innite.
Sweep Setting (2/2, Step mode)
Wavelength
Time
(D) Sweep
Perform two-way sweep by changing the wavelength
continuously. Change the wavelength from the start wavelength
to the end wavelength with the speed set by Speed. Afterwards,
change the wavelength from the end wavelength to the start
wavelength in the same manner. The wait time between each
sweep is set by Delay.
delay
delay
