PLC-WU3800 Expand Serial Command Functional Specifications
21/74
8.4.11 CF_IMAGE Command
Command
“CF_IMAGE_%1”[CR]
%1
“DYNAMIC” ------ Dynamic (Fixed value to enable projection with a sharp, powerful
picture tone)
“STAND” ---------- Standard (Image adjust value is set to factory default)
“REAL” ------------ Real (Fixed value to display graphic image with natural tone)
“CINEMA” -------- Cinema (Fixed value to focus on tone reproduction for movie)
“BLACKBOARD” – Blackboard (Fixed value to project image onto green-colored
blackboard)
“COLORBOARD ” – Colorboard(Fixed value to project image onto colored board)
“CUSTOM1” ----- Image1 (the value set and stored by a user)
“CUSTOM2” ----- Image2 (the value set and stored by a user)
“CUSTOM3” ----- Image3 (the value set and stored by a user)
“CUSTOM4” ----- Image4 (the value set and stored by a user)
Details
Select Image Mode
Parameter “CUSTOM1 to “CUSTOM4 is the same as “Image1” to “Image4”
displayed when selecting Image on OSD menu.
The value set by this command is stored in EEPROM and its setting is effective
even after ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“Error Code[CR]
8.4.12 CF_IMAGEADJ Command
Command
“CF_IMAGEADJ_%1”[CR]
%1
“RST” ------- Reset Image adjustment
“STR1” ----- Store current Image adjustment to Image 1
“STR2” ----- Store current Image adjustment to Image 2
“STR3” ----- Store current Image adjustment to Image 3
“STR4” ----- Store current Image adjustment to Image 4
Details
Reset / store Image adjustment.
Parameter “STR1” to “STR4” is the same as “Image1” to “Image4” displayed when
adjusting Image on OSD menu and selecting “Store
The value stored to “Image1-4” is saved and its setting is effective even after ALL
is OFF.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“Error Code[CR]
