PLC-WU3800 Expand Serial Command Functional Specifications
                                       
31/74
8.7.3 CF_KEYSTONE Command
Command “CF_KEYSTONE_%1”[CR]
%1
“UP” ------------- Correct Keystone distortion to reduce upper part of image
“FUP” ----------- Correct Keystone distortion to reduce upper part by 2steps
“DN” ------------- Correct Keystone distortion to reduce lower part of image
“FDN” ----------- Correct Keystone distortion to reduce lower part by 2steps
“RST” ------------ Reset Keystone correction
Details
Change Keystone distortion correction
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“Error Code”[CR]
“201” [CR] ----When reaching the Keystone correction limit or
reaching 1 step to correction limit and “FDN”/”FUP”
is received.
         (The command is not executed)
8.7.4 CF_KYSTNMODE Command
Command “CF_KYSTNMODE_%1”[CR]
%1
“STR” --------- Set Keystone store mode to Store
“RST” --------- Set Keystone store mode to Reset
Details
Set Keystone store mode
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]
8.7.5 CF_VSCALE Command
Command “CF_VSCALE_%1”[CR]
%1
“032” --------- +32
“031” --------- +31
  ：
“002” --------- +2
“001” --------- +1
“000” --------- +0
“-01” ---------- -1
“-02” ---------- -2
  ：
“-31” ---------- -31
“-32” ---------- -32
“UP” ---------- Vertical Scale setting value + 1
“DN” ---------- Vertical Scale setting value - 1
Details
Set Vertical Scale
This command is available in normal Power ON status.
Note1) Screen mode is changed into Custom by receiving this command.
Note2) When there is no Input, projector returns 101 and the command does not
execute.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]
