PLC-WU3800 Expand Serial Command Functional Specifications
                                       
38/74
8.10.8 CF_DISP Command
Command “CF_DISP_%1”[CR]
%1
“ON” ----------------------------- Select Display
“OFF” --------------------------- Cancel Display
“CNTDWNOFF” -------------- Count down OFF
“UP” --------------- Switch Display mode forward
（On → Countdown OFF → Off → On →…）
“DN” --------------- Switch Display mode backward
（On → Off → Countdown OFF → On →…）
Details
Set / Cancel Display
The value set by this command is stored in EEPROM and its setting is effective
even after ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]
8.10.9 CF_LOGO Command
Command “CF_LOGO_%1_%2”[CR]
%1 “0000”-”9999” ----------------- Set LOGO PIN CODE directly
%2
“OFF” ---------------------------- Disable Logo function
“DFLT” --------------------------- Display Default Logo
“USER” -------------------------- Display Captured Logo
“UP” --------------- Switch Logo setting forward
(OFF → DFLT → User → OFF → ・・)
“DN” --------------- Switch Logo setting backward
(OFF → User → DFLT → OFF → ・・)
Details
Set / Cancel Logo
The value set by this command is stored in EEPROM and its setting is effective
even after ALL is OFF
This command is available in normal Power ON status.
%1--- Set LOGO PIN CODE
- When LOGO LOCK is in operation
PIN CODE is correct ------------------ Command is valid (Acceptable)
PIN CODE is incorrect ---------------- Command is invalid (Error Code “102”)
PIN CODE is out of %1 range ------ Command is invalid (Error Code “? “)
-When LOGO LOCK is not in operation
PIN CODE is within %1 range ------ Command is valid
PIN CODE is out of %1 range ------ Command is invalid (Error Code “? “)
Note) Receiving correct LOGO PIN CODE while LOGO LOCK is in operation
enables to change LOGO setting, but it does not release LOGO LOCK. (LOGO
LOCK continues.)
Projector returns Error Code “101” by receiving USER in %2 when capture has not
operated.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
