PLC-WU3800 Expand Serial Command Functional Specifications
                                       
24/74
8.5.7 CF_DLINE Command
Command “CF_DLINE_%1”[CR]
%1
“0100”~”nnnn” --- Directly select Display Line setting value
“nnnn” shows maximum value, it is current Total Line value – Vertical
Position value
“UP” -------------- Current Display Line setting value + 1
“DN” -------------- Current Display Line setting value – 1
Details
Set Display Line value of PC signal
The value set by this command will not be saved to projector. Therefore, when
turning into Standby mode or ALL is OFF, the value returns to original setting.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected
8.5.8 CF_PCSTORE Command
Command “CF_PCSTORE_%1”[CR]
%1
“MODE1” ---- Store current PC Adjust status to Mode1
“MODE2” ---- Store current PC Adjust status to Mode2
“MODE3” ---- Store current PC Adjust status to Mode3
“MODE4” ---- Store current PC Adjust status to Mode4
“MODE5” ---- Store current PC Adjust status to Mode5
Details
Store current PC Adjust status (each parameter status such as Total dots) to
Mode1~Mode5. This command operates the same way as storing to
Mode1-Mode5 in PC Adjust MENU.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected
8.5.9 CF_PCMODEFREE Command
Command “CF_PCMODEFREE_%1”[CR]
%1
“MODE1” ---- Set Mode1 to Free status
“MODE2” ---- Set Mode2 to Free status
“MODE3” ---- Set Mode3 to Free status
“MODE4” ---- Set Mode4 to Free status
“MODE5” ---- Set Mode5 to Free status
Details
Delete the registered data in Mode1-Mode5 and turns it to Free status.
This command operates the same as turning Mode1-Mode5 to Free in PC Adjust
Menu.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
