PLC-WU3800 Expand Serial Command Functional Specifications
23/74
8.5.4 CF_H – POS Command
Command
“CF_H-POS_%1”[CR]
%1
“0000~nnnn” --- Directly select Horizontal Position setting value
“nnnn” shows maximum value, it is current Total Dots value - Display Dots value
“UP” -------------- Current Horizontal Position setting value + 1
“DN” -------------- Current Horizontal Position setting value - 1
Details
Set Horizontal Position value of PC signal.
The value set by this command will not be saved to projector. Therefore, when
turning into Standby mode or ALL is OFF, the value returns to original setting.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“101”[CR] ---- when Input for Video is selected
8.5.5 CF_V – POS Command
Command
“CF_V-POS_%1”[CR]
%1
“0000~nnnn” --- Directly select Vertical Position setting value
“nnnn” shows maximum value, it is current Total Line value - Display Line value
“UP” -------------- Current Vertical Position setting value + 1
“DN” -------------- Current Vertical Position setting value – 1
Details
Set Vertical Position value of PC signal
The value set by this command will not be saved to projector. Therefore, when
turning into Standby mode or ALL is OFF, the value returns to original setting.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“101”[CR] ---- When Input source is Video system
8.5.6 CF_DDOTS Command
Command
“CF_DDOTS_%1”[CR]
%1
“0256”~”nnnn” --- Directly select Display Dots setting value
“nnnn” shows maximum value, it is current Total Dots value - Horizontal
Position value
Even number is available and when odd number is set, it is rounded out.
“UP” -------------- Current Display Dots setting value + 2
“DN” -------------- Current Display Dots setting value – 2
Details
Set Display Dots value of PC signal
The value set by this command will not be saved to projector. Therefore, when
turning into Standby mode or ALL is OFF, the value returns to original setting.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable
“101”[CR] ---- When Input for Video is selected
