PLC-WU3800 Expand Serial Command Functional Specifications
                                       
53/74
9.5.5 CR_V – POS Command
Command
“CR_V - POS”[CR]
Details Get Vertical Position value
Response
Acceptable “000_%a”[CR]
%a
“0000”~“nnnn”
(nnnn = Total Line - Display Line)
Unacceptable
“Error Code”[CR] -------- When the command is invalid due to
condition such as Input source
“?”[CR] ----------------------- When unclear command is received
9.5.6 CR_DDOTS Command
Command “CR_DDOTS”[CR]
Details Get Display Dots value
Response
Acceptable “000_%a”[CR]
%a
“0256”~“nnnn”
(nnnn = Total Dots – Horizontal Position value)
Unacceptable
“Error Code”[CR] -------- When the command is invalid due to
condition such as Input source
“?”[CR] ----------------------- When unclear command is received
9.5.7 CR_DLINE Command
Command “CR_DLINE”[CR]
Details Get Display Line value
Response
Acceptable “000_%a”[CR]
%a
“0100”~“nnnn”
(nnnn = Total Line – Vertical Position value)
Unacceptable
“Error Code”[CR] -------- When the command is invalid due to
condition such as Input source
“?”[CR] ----------------------- When unclear command is received
9.5.8 CR_PCSTORE Command
Command “CR_PCSTORE”[CR]
Details
Get Free/Stored status of MODE1 - MODE5 for PC Adjust
Each data consists of 5 bytes.
Each byte indicates the status of MODE1~MODE5 respectively.
(F:Free S:Stored)
Response
Acceptable “000_%a”[CR]
%a
“FFFFF” ----------- All Free
“SFFFF” ----------- MODE1 is Stored, others are Free
 :
“FFFFS” ----------- MODE5 is Stored, others are Free
“SSSSS” ---------- All Stored
Unacceptable “Error code”[CR]
