PLC-WU3800 Expand Serial Command Functional Specifications
                                       
41/74
Unacceptable “Error Code”[CR]
8.10.18 CF_PIPPOSITION Command
Command “CF_PIPPOSITION_%1”[CR]
%1
“BTMRIGHT” ----------------------- Move Subpicture to Bottom right
“BTMLEFT” ------------------------- Move Subpicture to Bottom left
“TOPRIGHT” ----------------------- Move Subpicture to Top right
“TOPLEFT” ------------------------- Move Subpicture to Top left
“UP” ------------------------------ Switch Subpicture position forward
（Bottom right →Top right →Top left→Bottom left →）
“DN” ------------------------------ Switch Subpicture position backward
（Bottom left →Top left →Top right →Bottom right→）
Details
Select Subpicture position of Picture in Picture.
This command is available in normal Power ON status.
Note) Projector returns “101” by receiving this command when Picture in Picture is
Off.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]
8.10.19 CF_P-MANE Command
Command
“CF_P−MANE_%1”[CR]
%1
“OFF” --------------------------------- Set Power Management to OFF
“READY” ----------------------------- Set Power Management to Ready
“SHUTDOWN” --------------------- Set Power Management to Shut Down mode
“UP” ------------------------------ Switch Power management setting
（Off → Ready → Shutdown → Off）
“DN” ------------------------------ Switch Power management setting
（Off → Shutdown → Ready → Off）
Details
Set/Cancel Power Management
The status set by this command is stored in EEPROM and its setting is effective
after ALL is OFF
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “Error Code”[CR]

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
