BioPAT
®
Trace | Multi Trace Operating Instructions 41
Initial Installation
Dialysis mode
Interval Buffer consumption 10 L for:
min µl/min ml/h ml/d h d
120 141.3 8.5 203.5 1,179 49
180 127.0 7.6 182.8 1,313 55
360 112.6 6.8 162.2 1,480 62
CAUTION
Erroneous measurements due to tubing sets not being filled or only being
partly filled!
Before filling the tubing set, make sure that tubing is connected to all
solutions and that the vessels are sufficiently filled.
6.1.2 Tubing Set Connectors on the Device
BioPAT
®
Trace | Multi Trace is equipped with the corresponding tubing set
(fluidics).
You will find the corresponding instructions for attaching the tubing set
below.
The tubing set consists of the components necessary for analysis:
Pump cassettes, valve tubes, diffusion module, drip counters and connection
lines for buffers, standards, waste as well as the sampling probe (dialysis
probe, dialysis module).
