86
Specifications
Models LMA100P LMA110S
Display of Results 0�001% 0�001%
Balance Resolution 0�0001 grams 0�0001 grams
Balance Capacity 100 grams 40 grams
Reproducibility of the Sample weight = 1g : 0�1%
measurement Sample weight = 5g : 0�02%
Balance Repeatability ±0�1 mg ±1�0 mg
Method of Measurement Loss on Drying
Modular Configuration: (Optional: (Optional:
Control and heater modules up to 4 heater modules) up to 2 heater modules)
Heat Source Four parallel infrared quartz cylinders
Temperature Setting/Control 30–210°C in one-degree increments/RTD sensor, ±1°C
Temperature Steps Programmable, one or two with Programmable, one or two
selectable ramp rate
Temperature Adjustment Optional fixture for internal electronic two-point adjustment
Standby Temperature 30–160°C in one degree increments 30–160°C in one
with selectable equilibration time degree increments
Temperature Display Display of both target and current temp at each stage of drying and standby
Conserve Mode Clock Programmable time by day of week to shut down and wake up analyzer
Balance Calibration Internal calibration weight or external manual External manual
Ideal Weight Audio and visual display for programmable target sample weight addition
Target Limit Alert Minimum and maximum programmable limits and screen alert when test done
Program Storage with unique
settings, alphanumeric naming 300 programs 60 programs
Result Storage 999 results with statistics: average, SD, RSD, high and low
Units of Measure of Results Weight, %moisture, %solids, %volatiles, PPM, ppm moisture, ppm solids, mg
Endpoint Determination Actual slope, Calculation and Windows of Time modes
Sample ID Numeric, Numeric incrementing, alphanumeric or turned off
Modes of Operation Standard Test, Syringe or Concentration modes –
Operator Names Twenty alphanumeric operator names
Security Mode Selectable setup and operation protection with pass code
Graph Mode Graph of Temperature/Time and Percent/Time
Display Quarter VGA with contrast adjustment (black on white or white on black)
Keypad Sealed membrane with audible tactile feedback
Internal Printer Thermal, 40-character graphic with –
selectable format without internal printer
External Input|Output Serial
Internal Clock Date and Time: U�S� or International, Military or AM|PM
Audio Beep Key stoke, ideal weight met and end of test, selectable on or off
System Status Indicator Lights Two tri-color LEDs (balance & heater) on front of heater module
Power Requirements 100–120/200–240 V~ ~5A T
Dimensions (L + W + H) 41�3 + 49�5 + 23�5 cm (16 1/4” + 19 1/2” + 9 1/4”) modules combined
Weight 10 kg (22 lbs�)
