22 VERSA SATEL
Control panel settings
Parameters and options related to modem communication are described in section “Global
parameters” (p. 26).
3.2.3 Ethernet communication parameters
Programming the parameters
DLOADX program settings
You can configure the Ethernet communication settings in the “Identifiers and tel. no”
window.
Ethernet module settings
You can configure the Ethernet communication settings when programming the Ethernet
module (see: “Ethernet module” p. 51).
Description of the parameters
DLOADX program settings
Connection – you can define two sets of parameters:
LAN/WAN – parameters for communication via local or wide network.
LAN: ETHM-1 – parameters for communication via local network only. In this case, the
port number and data encryption key programmed in the settings of Ethernet module.
Server – address of the Ethernet module. If the Ethernet module is not in the same local
network as the computer with DLOADX program, it must be a public address. You can
enter either the IP address or the domain name.
Port – the number of TCP port used for communication between the control panel and
computer with DLOADX program via Ethernet. You can enter a value from 1 to 65535.
Default value: 7090.
DLOADX key – a string of up to 12 alphanumeric characters (digits, letters and special
characters), used for data encryption during communication between the control panel and
the computer with DLOADX program via Ethernet.
ETHM-1 ID – individual identification number of the Ethernet module for the purpose of
communication via the SATEL server.
ETHM-1 MAC – hardware address of Ethernet module.
Control panel settings
For parameters and options related to communication via Ethernet, see section “Ethernet
module” (p. 51).
3.3 Local programming
3.3.1 Starting local programming
1. Connect the control panel RS-232 (TTL) port with the computer port (for example, by
means of the USB-RS converter offered by SATEL).
2. Start the DLOADX program.
3. If the control panel is connected to other computer port than COM1, click on in the
main menu. The “Configuration” window will open, in which you can select the COM port
to which the control panel is connected.
