82 VERSA SATEL
12.4 Confirmation on LEDs in the APT-100 keyfob
The list of information that may be presented on the keyfob LEDs is numbered, which makes
programming easier (use the and keys to scroll through the list in the keypad). In
the LED keypad, the number is presented in binary format on LEDs 1-12, in a similar way as
the decimal values (see: page 10, Table 4). Only the values corresponding to the numbers on
the list can be entered.
0. On LED is ON when the control panel has confirmed
receiving information on a keypress
1. Output 1 state LED is ON when the selected output is active
2. Output 2 state
3. Output 3 state
4. Output 4 state
5. Output 5 state
6. Output 6 state
7. Output 7 state
8. Output 8 state
9. Output 9 state
10. Output 10 state
11. Output 11 state
12. Output 12 state
13. Arming: Partition 1 LED is ON when partition 1 is armed
14. Arming: Partition 2 LED is ON when partition 2 is armed
15. Arming: Partition 1 or 2 LED is ON when partition 1 or 2 is armed
16. Arming: Partition 1 and 2 LED is ON when partitions 1 and 2 are armed
17. Partition 1 – Full arm LED is ON when partition 1 is fully armed
18. Partition 1 – Night arm LED is ON when partition 1 is armed in night mode
19. Partition 1 – Day arm LED is ON when partition 1 is armed in day mode
20. Partition 2 – Full arm LED is ON when partition 2 is fully armed
21. Partition 2 – Night arm LED is ON when partition 2 is armed in night mode
22. Partition 2 – Day arm LED is ON when partition 2 is armed in day mode
23. Partition 1 – Alarm LED is ON when there is alarm in partition 1
24. Partition 2 – Alarm LED is ON when there is alarm in partition 2
25. Partition 1 or 2 – Alarm LED is ON when there is alarm in partition 1 or 2
26. Trouble LED is ON when there is trouble in the system
27. Partition 1 – Not armed LED is ON when partition 1 is disarmed
28. Partition 2 – Not armed LED is ON when partition 2 is disarmed
29. Partition 1+2 – Not armed LED is ON when partitions 1 and 2 are disarmed
255. NOT PRESENT LED will not be used for confirmation
13. Compliance with EN 50131 standard requirements for Grade 2
To meet the requirements of EN 50131 standard for Grade 2, do the following:
enable the global options:
– G
RADE 2,
– T
ROUBLE MEMORY UNTIL REVIEW,
