violation will block verification, and the zone restore will shorten the exit delay time. The
option is available, if the BLOCKS VERIFICATION option is enabled.
Alarm clearing – an option for the 13. ARM/DISARM and 15. DISARMING zone types. If the
option is enabled, together with disarming, the alarm is cleared (except for the tamper
alarms). Violation of the 15. DISARMING type zone will also clear the alarm, when the
system is not armed.
Store to event log – an option for the 12: NO ALARM ACTION zone type. If the option is
enabled, violation of the zone is saved into the event log (the way of saving the event
depends on the KEYBOX CONTROL option).
Store event only if armed – an option for the 12: NO ALARM ACTION zone type. If the option is
enabled, zone violations are saved in the event log when the partition to which the zone
belongs is armed. The option is available when the STORE TO EVENT LOG option is
enabled.
Keybox control – an option for the 12: NO ALARM ACTION zone type. If this option is enabled,
violation of the zone will result in logging an event which informs that the keybox is open.
The event code is sent to the monitoring station. If this option is disabled, an event will be
logged informing about zone violation, which will not be reported. The option is available
when the STORE TO EVENT LOG option is enabled.
LED
Name displayed on
LCD keypad
Options Zone type
1
Al.on exit end Alarm on exit delay end 0-10
2
Priority Priority all
3
Bypass disabled Bypass disabled all
4
Active night arm Active in night arm 0-4
5
Active day arm Active in day arm 0-4
6
Power up delay Power-up delay all
7
Warn.in part.arm Warning in partial arming 0-4
Warning on internal sirens 0-4
8
Warn.on int.sir.
Signaling on internal sirens 19
9
Auto-bypass 3 Auto-reset 3 0-10, 19
10
Auto-bypass 1 Auto-reset 1 0-10, 19
11
Autobypass reset Clearing Autoreset 0-10, 19
Armed if one part. armed 0-4
12
Arm.with one p.
Keybox control
12
Blocks verification 0, 1, 17
13
Disable verific.
Store to event log
12
Restore disarms 17
Restore disables verif. 17
Store event only if armed 12
14
Finish exit time
Alarm clearing 13, 15
Table 5. The method of presenting zone options on keypads. In graphic mode, the options in
the LCD keypad are numbered in the same way as in the LED keypad.
6.6 Hardware
Numbers of zones on the mainboard, in zone expanders and wireless system controllers may
overlap. If the zone numbers overlap, the state of only one of them will be supervised. Select
the zone that is to be supervised.
