SATEL VERSA 51
Arming
Card hold-down – if you select this option, the user will have to bring the card close to the
keys and hold it still for about 3 seconds to arm the system.
Card read – if you select this option, the user will only have to bring the card close to the
keys to arm the system.
When configuring the keypad by using functions available in the service mode, use the
PROX.CARD - ARMS option to define how to arm the system using the proximity card
(option enabled = CARD READ; option disabled = CARD HOLD-DOWN).
Card hold-down control outputs
If you have selected the CARD READ option, you can permit the users to toggle the
15. CONTROLLED type outputs (the output status will change after the card is brought close to
the keys and held still for about 3 seconds). Select the outputs the users will be allowed to
control.
8.3 Ethernet module
The parameters and options, as described below, apply to the ETHM-1 Plus module
with firmware version 2.04.
DLOADX
DLOADX->ETHM-1 connection [DLOADXETHM-1] – if this option is enabled, it is
possible to initiate connection with the control panel via Ethernet from the DLOADX
program.
DLOADX server – address of the computer with DLOADX program. If the computer is not in
the same local network as the control panel, it must be a public address. You can enter
either the IP address or the domain name.
Port – number of the TCP port used for communication between control panel and
a computer with DLOADX program via Ethernet. You can enter values from 1 to 65535.
Default value: 7090.
DLOADX key – a string of up to 12 alphanumeric characters (digits, letters and special
characters) which is used for data encryption during communication between control panel
and computer with DLOADX program via Ethernet.
SATEL service
LAN [SATEL server LAN] – if this option is enabled, the control panel connects to the SATEL
server via the Ethernet module, while the SATEL server makes it possible to establish
communication with the control panel. For communication vie the SATEL server, you do
not need to additionally configure the network device through which the module connects
to the public network.
For establishing communication with the SATEL server, the DNS server must be used.
For communication via the SATEL server, the ports of 1024-65535 range are used as
outgoing ports. These ports must not be blocked.
Do not report SATEL server connection trouble [No SATEL trbl.] – if this option is
enabled, loss of communication with the SATEL server will not be reported.
Communication with mobile application [Mobile app.] – if this option is enabled,
communication with the control panel can be established from the mobile application. The
option is available if the LAN option is enabled.
