64 VERSA SATEL
that no values exceeding 300 ms should be entered when programming the sensitivity
(the higher the value, the lower the sensitivity).
The expander informs you about the zone status as it changes. Also the expander outputs
are controlled in real time. Only the programming of zones takes place during the response
time (in one period, data relating to configuration of one zone are sent to the expander
module, i.e. sending the information on settings of four zones require four response periods).
If communication with the controller is lost, all previously activated outputs will be
deactivated after 20 response periods.
Additionally, the ACX-201 expander module sends information about:
status of AUX1 and AUX2 power supply outputs – information on overload is sent when
the AUX1 or AUX2 output load exceeds 0.5 A.
battery status – information on low battery is sent when the battery voltage drops below
11 V for more than 12 minutes (3 battery tests). The expander will kept sending this
information to the controller until the battery voltage rises and remains above 11 V for
longer than 12 minutes (3 battery tests).
AC power status – information on the loss of power supply is sent when the AC power loss
lasts for more than 30 seconds. The AC power restore is reported with the same delay.
Low battery information for the first zone of ACX-201 expander indicates overload of the
AUX1 or AUX2 power supply output, for the second zone – discharged battery, for the third
zone – loss of AC power.
230 V AC wireless controllers
Activation of the output to which the controller is assigned will result in energizing the
230 V AC electrical circuit (if reverse polarity of the output has been programmed, the circuit
will be deenergized).
Depending on the operating mode, information on the button status (mode 0) or on the
electric circuit status (mode 1 and mode 2) is sent to the zone to which the controller is
assigned. Information on the button status is sent in real time. Information on the electric
circuit status is sent during the response time. Pressing the button / closing the electric circuit
means violation of the zone to which the controller is assigned.
8.5 433 MHz wireless system controller
8.5.1 Presence control of 433 MHz wireless detectors
Presence control – if this option is enabled, the detector is checked for presence. If no
transmission is received from the detector within an hour, trouble will be reported (loss of
communication with the detector).
8.5.2 Configuring the 433 MHz wireless detectors
DLOADX program
You can enable/disable the presence control option: “VERSA – Structure” window
“Hardware” tab “Expansion modules” branch [VERSA-MCU controller name]. Before
making any changes, click on the “Read” button, and after making the changes – on the
“Write” button (the data relating to the 433 MHz wireless detectors are not read after clicking
on the button or saved after clicking on the button in the DLOADX program main
menu). To enable / disable the option, click on the “Presence contr.” column (symbol X
indicates that the option is enabled).
