SATEL VERSA 7
LEDs of the first and second partition show the number of programming step (see: page 10
table 4). Some programming steps may be sometimes not available.
2.5 Entering data
The changes entered will be saved after pressing the key. Use the key to quit
the function without saving changes.
2.5.1 LCD keypad
The data being entered are presented on the display. The method of programming depends
on the type of data to be entered by service function.
Selection from the single-choice list
In the upper line of the display, the function name is presented, and in the lower one – the
currently selected item. You can scroll through the list using the and keys. The
and keys are not used.
Selection from the multiple-choice list
In the upper line of the display, the function name is presented, and in the lower one – one of
the items to choose from. You can scroll through the list using the and keys. The
following symbol is situated in the upper right corner of the display:
– displayed item is selected / option is enabled,
– displayed item is not selected / option is disabled.
Press any numerical key to change the currently shown symbol for another one.
If you want to see the status of all items (these can be e.g. zones, outputs, options, etc.),
press or . The numbers around the display allow the items to be identified. Use
the and keys to move the cursor. After hovering the cursor over the selected
item, you can change its status by pressing any numeric key. If you want to restore the
previous way of presentation of the list, press or .
Entering decimal values
To enter digits, use the numeric keys. The key moves the cursor to the right, and the
or key – to the left.
Entering hexadecimal values
To enter digits, use the numeric keys, and to enter characters from A to F, use the
and
keys (keep pressing the key until the required character appears). The key
moves the cursor to the right, and the or key – to the left.
Programming telephone numbers
To enter digits, use the numeric keys, and to enter other characters, use the , ,
and keys (keep pressing the key until the required character appears – see:
table 1). You can enter up to 16 characters. Some of the characters occupy two positions (a,
b, c, d, # and ). If they are used, you can enter less characters than 16.
Shown on the right side in the upper line of the display is information about the letter case:
[ABC] or [abc] (it will be displayed after pressing any key and will be visible for a few seconds
after the last keystroke). Use the and keys to move the cursor. The key
deletes the character on the left side of the cursor.
