44 VERSA SATEL
14. RAM memory error
15. Mainboard TMP open
16. Zones – tamper
17. Zones – long violation
18. Zones – no violation
19. Zones – masking
20. Wireless device battery low
21. Wireless device communication loss
22. Module tamper
23. No presence (module)
24. AC loss (module)
25. Battery trouble (module)
26. Power output overload (module)
27. Low battery (keyfobs)
28. Module restart
29. Control panel restart
For the 22. ETHM TROUBLE STATUS output function, these can be the following troubles (the
number corresponds to the LED number in the LED keypad and to the item number in
graphic mode in the LCD keypad):
1. Reporting trouble – station 1 – ETHM
2. Reporting trouble – station 2 – ETHM
21. No Ethernet connection
22. No Ethernet connection (PING)
23. No connection to SATEL server
24. Wrong pair MAC/ID
7.4 Output options
Clearing from part. 1 / Clearing from part. 2 – depending on the output function:
– alarm outputs – the alarm can be cleared by users having access to the selected
partition,
– the 1. EXTERNAL SIREN and 2. INTERNAL SIREN outputs with enabled ARM/DISARM/CLEAR
SIGN
. option – the output will be activated when in the selected partition the procedure of
arming has been initiated, arming is not possible, armed mode is deactivated, or when
alarm is cleared in it,
– 5. “DURESS” ALARM – the users having access to the selected partition can deactivate
the output by means of the OUTPUTS RESET user function.
Partition 1 / Partition 2 – depending on the output function:
– 12. POWER SUPPLY ON ARMED – the output is active when the selected partition is armed
(it activates after starting the arming procedure, without taking the exit delay into
account),
– 15. CONTROLLED – the output can be controlled by the users having access to the
selected partition by means of the user function CONTROL (if no partition is selected, the
function CONTROL will not be available in the keypad),
– 17. E
XIT DELAY STATUS – the output is active when the exit delay countdown is running in
the selected partition,
