SATEL VERSA 57
ASP-205 – wireless indoor siren. Signaling parameters can be programmed for both
positions occupied by the siren (thus allows to program two different signaling types):
 maximum duration of signaling (optical and acoustic),
 type of acoustic signaling,
 optical signaling option.
ASW-100 E / ASW-100 F – 230 V AC wireless controller. Operating mode can be
programmed.
8.4.3 Configuring the ABAX wireless devices
DLOADX program
You can configure the wireless devices as follows: “VERSA – Structure” window
“Hardware” tab “Expansion modules” branch [ABAX system controller name]
“Zones/Outputs” tab. Before making any changes, click on the “Read” button, and after
making the changes – on the “Write” button (the data relating to the wireless devices are not
read after clicking on the
button or saved after clicking on the button in the
DLOADX program main menu). Described below is how the additional parameters and
options should be programmed in the “Configuration” column.
AGD-100 – enter a digit from the 1 to 3 range to set the sensitivity (1 – low, 2 – medium,
3 - high).
AMD-100 / AMD-101 – enter the digit 0 (bottom reed switch) or 1 (side reed switch) to
determine which of the two reed switches is to be active.
AMD-102 – for the magnetic contact, enter the digit 0 (bottom reed switch) or 1 (side reed
switch) to determine which of the two reed switches is to be active. For the roller shutter
input, enter 2 digits:
1
st
digit – number of pulses: from 1 to 8.
2
nd
digit – pulse validity: 0 (30 seconds), 1 (120 seconds), 2 (240 seconds) or 3 (unlimited
duration).
AOCD-250 – enter 2 digits:
1
st
digit – sensitivity of PIR sensor: from 1 to 4 (1 – minimum; 4 – maximum).
2
nd
digit – sensitivity of microwave sensor: from 1 to 8 (1 – minimum; 8 – maximum).
AOD-200 – for the first position taken by the detector, enter 3 digits:
1
st
digit – sensitivity of PIR sensor: from 1 to 4 (1 – minimum; 4 – maximum).
2
nd
digit – sensitivity of microwave sensor: from 1 to 8 (1 – minimum; 8 – maximum).
3
rd
digit – sensitivity of dusk sensor: from 1 to 4 (1 – minimum; 4 – maximum).
APMD-150 – enter 3 digits:
1
st
digit – sensitivity of PIR sensor: from 1 to 4 (1 – minimum; 4 – maximum).
2
nd
digit – sensitivity of microwave sensor: from 1 to 8 (1 – minimum; 8 – maximum).
3
rd
digit – the way of operation in the test mode: 0 (alarm triggered after motion is sensed
by both detectors), 1 (alarm triggered after motion is sensed by infrared detector) or 2
(alarm triggered after motion is sensed by microwave detector).
APD-100 – enter 2 digits:
1
st
digit – sensitivity: 1 (low), 2 (medium) or 3 (high),
2
nd
digit – pet immunity option: 0 (disabled) or 1 (enabled).
ARD-100 – enter a number from the 1 to 16 range to determine sensitivity (1 – minimum;
16 – maximum).
