72 VERSA SATEL
station. You can program a number of days, hours, minutes and seconds between the
transmissions. Entering zeros only means that no additional transmission will be sent.
Fig. 22. DLOADX program: “SIA-IP” tab in “VERSA – Reporting” window.
10.4 Event codes
For the pulse and Ademco Express formats, it is necessary to program codes which will be
reported to the monitoring station if the defined events occur. An event code consists of 2
hexadecimal characters (digits or letters from A to F). The reported events are those for
which a code different from “00” has been programmed.
For the Contact ID and SIA formats, event codes consistent with format specification are
sent. In case of the CONTACT ID (SELECTED) and SIA (SELECTED), the codes must be
programmed at the events which are to be reported (not the programmed code, but a code
consistent with the format specification will be sent).
10.5 Starting the reporting
1. Get the data necessary to properly start the reporting from the monitoring station
operator:
depending on the transmission path:
telephone number of the monitoring station (reporting via telephone line),
server address, TCP port number, STATION KEY and ETHM KEY (reporting via
Ethernet network).
transmission format required by the monitoring station,
identifiers assigned to the alarm system,
list of event codes (not applicable to Contact ID and SIA formats).
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (enable one of the options: S
TATION 1 OR 2, STATION 1, STATION 2 or STATION 1
AND
2).
3. Determine whether the number of events from the same source is to be limited (EVENTS
AMOUNT LIMITING
option).
4. Determine when the restore code is to be sent (RESTORE AFTER BELL, RESTORE AFTER
DISARM
options).
