26 VERSA SATEL
Initiating an Ethernet connection by the control panel
Ethernet module settings (see: “Ethernet module” p. 51):
 program the address of the computer with DLOADX program, the number of TCP port
which will be used for communication and the data encryption key,
 configure the Ethernet communication module.
DLOADX program settings:
 program the number of TCP port which will be used for communication and the data
encryption key (or select the “LAN: ETHM-1” parameter set – the data programmed in
settings of Ethernet module will be used).
1. Click on the button in DLOADX program main menu. A drop down menu will be
displayed.
2. Click “TCP/IP: DLOADX <- ETHM”. The “Connection TCP/IP: DLOADX<-ETHM-1”
window will be displayed.
3. Ask the user to start the function ETHM-1DLOADX (he is supposed to enter the code
and press , and then press in turn ). The control panel will
connect to the computer network address.
4. When communication is established, the DLOADX program will inform you about it.
Communication via the SATEL server
Ethernet module settings (see: “Ethernet module” p. 51):
 enable DLOADX->ETHM-1 CONNECTION and SATEL SERVER options,
 program the data encryption key.
DLOADX program settings:
 enter the individual identification number of the Ethernet module for the purpose of
communication via the SATEL server,
 enter the MAC address of Ethernet module,
 program the data encryption key.
1. Click on the button in DLOADX program main menu. A drop down menu will be
displayed.
2. Click “TCP/IP: Satel server”. The “Connection TCP/IP: DLOADX<->ETHM-1” window will
be displayed.
3. Click on the “Connect” button in the “Connection TCP/IP: DLOADX<->ETHM-1” window.
Connection establishment information will be displayed.
4. When communication is established, the DLOADX program will inform you about it.
4. Global parameters
4.1 Programming the global parameters
You can program the global parameters:
 DLOADX program: “Global parameters” window.
 keypad: functions available in the GLOBAL PARAM. submenu (SERVICE MODE 3. GLOBAL
PARAM
.).
