24 VERSA SATEL
DLOADX program settings:
 program the telephone number of control panel,
 configure the modem communication parameters.
1. Click on the button in DLOADX program main menu. A drop down menu will be
displayed.
2. Click “Modem 300bps”. Window with modem initialization information will be displayed.
3. After modem initialization, click on the “Connect” button. Information on connection
establishment will be displayed.
If the DOUBLE CALL option is enabled in the control panel, select the “Double call” field
before pressing the “Connect” button.
4. When the control panel goes off hook, connection will be established, of which you will be
informed by the DLOADX program.
Initiating a modem connection from DLOADX program, with control panel calling back
and making the call
Control panel settings:
 program the telephone number of modem connected do computer (PC PHONE NUMBER),
 enable ANSWERING – MODEM option (see: “Global options” p. 27),
 define the number of rings after which the control panel will answer incoming calls – RINGS
BEFORE ANSWER
(see: “Other global parameters” p. 31),
 enable the DOUBLE CALL option if the control panel is to answer only after the second call
(see: “Global options” p. 27),
 configure the telephone communicator options (see: “Global options” p. 27).
DLOADX program settings:
 program the telephone number of control panel,
 configure the modem communication parameters.
1. Click on the button in DLOADX program main menu. A drop down menu will be
displayed.
2. Click “Modem 300bps”. Window with modem initialization information will be displayed.
3. After modem initialization, click on the “Connect” button. Information on connection
establishment will be displayed.
If the DOUBLE CALL option is enabled in the control panel, select the “Double call” field
before pressing the “Connect” button.
4. The control panel will receive the call, but will hang up. The DLOADX program will inform
you that the control panel will call back.
5. The control panel will call back the number of computer modem. The DLOADX program
will receive the call automatically or the program operator must accept establishing
communication (which depends on DLOADX settings).
Initiating a modem connection by control panel
Control panel settings:
 program the telephone number of modem connected to computer (PC PHONE NUMBER),
 configure the telephone communicator options (see: “Global options” p. 27).
