SATO CG2 Series User Manual

Section 7: Interface Specifications
CG2 Series Operator Manual Page 7-17
7.4 LOCAL AREA NETWORK (LAN) ETHERNET AND WIRELESS LAN (cont’d)
[Connectable combination]
*1 The following items should be specified for WPA-IEEE802.1x (TKIP).
Security Mode : WPA
WPA Authentication : EAP(IEEE802.1x)
WPA PSK Mode : TKIP
EAP Mode : EAP-LEAP / EAP-TLS / EAP-PEAP / EAP-TTLS
EAP User Name : (user name)
EAP Password : (password)
*2 The following items should be specified for WPA2-IEEE802.1x (AES).
Security Mode : WPA2
WPA Authentication : EAP(IEEE802.1x)
WPA PSK Mode : AES
EAP Mode : EAP-LEAP / EAP-TLS / EAP-PEAP / EAP-TTLS
EAP User Name : (user name)
EAP Password : (password)
For WPA-802.1x authentication, it is not necessary to set [WPA-PSK Setting].
Pre-Shared Key setting of [WPA-PSK Setting] must be configured when WPA mode is set to “PSK”. Match
“Data encryption: AES / TKIP” of [WPA Setting] with data encryption setting of access point. You cannot
establish the connection to the access point if data encryption setting is set to “AUTO”(TKIP / AES Auto-
detect).
Security IEEE 802.11 IEEE 802.11i Encryption
None None None None
WEP Open System None WEP key
Shared Key None
WPA None PSK TKIP
EAP-LEAP
EAP-TLS
EAP-PEAP
EAP-TTLS
WPA2 None PSK AES
EAP-LEAP
EAP-TLS
EAP-PEAP
EAP-TTLS
Dynamic WEP Open System EAP-LEAP WEP key
EAP-TLS
EAP-PEAP
EAP-TTLS
Shared Key EAP-LEAP
EAP-TLS
EAP-PEAP
EAP-TTLS
*1
*2
