Glossary
A.3 Glossary
AWL Statement list (program code line for line).
Backup Data backup (for example, copy to additional data carriers)
Basic address First numeric address of the IO module slot.
Buerbattery Thebuerbatterysuppliestheenergyformaintainingmemory
contents and to enable the clock to continue working after
switchingothepowersupply.
Builder CombinesdierentworkstepstoloadaprogrammeinthePCD.
Compiler A compiler is a program that translates the source code of a
program into the strings understandable to the target computer.
CPU Central Processing Unit. Here the main housing with central unit
is designed for the Saia PCD
®
family.
Device Device→controller(partofaprojectintheSaiaPG5
®
Project
Manager).
Download Abbr.DnLd→SavedatainPCD
Element Here,theinputsandoutputs,ag,register,counter,timer,etc.are
designed for the Saia PCD
®
family.
Flash memory Digital,non-volatilememory.Retainsitsdataintheostate.
FRAM Ferroelectric Random Access Memory
(requires no power supply for data retention)
IL Instructionlist→PCDprogramcode
Linker After the compiler has done its work, the linker merges the
individual data for a program.
LIO (Local Input Output) Inputs/outputs on the CPU board (on-board).
Media Thisindicatesinputs/outputs,ag,register,etc.inthePCDfamily.
Media mapping SoftwareassignmentofdigitalandanalogI/Oelectronicstoags
and registers.
Module holders CPU, LIO or RIO devices that can accept I/O modules (e.g.
PCD3.C100, etc.)
Modules Carrier cards for input/output electronics with suitable connection
technology.
Motherboard Main board (CPU)
NT Newtechnology→subsequentgenerationoftherstPCD
generation.
On-Board Denotes as much as permanently installed “on the CPU
motherboard”.
Parse A parser is a program which, in computer engineering, is
responsible for the decomposition and conversion of any input
(text, e.g. AWL) into a format useful for further processing.
PCD3.M6xxx x in the product description stands for a number 0...9. In this
case, it is an additional three-digit number, e.g. PCD3.M6560.
PGU Programmable Unit
PLC Process Logic Controller
Port Interface description
PWM PWM stands for Pulse Width Modulation. Pulse width modulation
works with a constant pulse rate and a constant pulse amplitude,
only the pulse width is variable. Because the pulse rate is
constant, but the pulse width changes, the pulse duty factor
changes.
With a PWM output, it is possible to output analog values without
expensive A / D converters
