Saia-Burgess Controls AG
Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
Communication interfaces
5-14
Plug-in interface modules on I/O slot 0 - 3
5
Slot interface modules made for the following control units
Module (excluding
Ethernet)*
Module Power module RIO
PCD3.M3020* PCD3.M3120 PCD3.M3160 PCD3.T660
PCD3.M3230* PCD3.M3330 PCD3.M3360 PCD3.T664
PCD3.M5340 PCD3.M5360 PCD3.T665
PCD3.M5440* PCD3.M5540 PCD3.M5560 PCD3.T666
PCD3.M6340 PCD3.M6360
PCD3.M6540 PCD3.M6560
PCD3.M6860
PCD3.M6880 PCD3.T668
* not recommended for new projects
5.4.2 Serial Interfaces on I/O module slot 0 (port 1)
RS-232 / RS-422 / RS-485, Belimo, current loop 20 mA with PCD3.F1xx
The communication modules PCD3.F1xx are described in manual:
26-857 PCD3.F1xx and PCD3.F2xx serial interface modules.
5.4.3 Serial interfaces on the I/O module slots 0 - 3
RS-232 / RS-422 / RS-485, Belimo, current loop 20 mA on PCD3.F2xx
The communication modules PCD3.F2xx are described in manual:
26-857 PCD3.F1xx and PCD3.F2xx serial interface modules.
DALI interface module PCD3.F261
The Dali communication modules are described in manual:
27-606 DALI modules PCD2.F2610 & PCD3.F261.
The description of the software library can be found in manual:
27-607 StarterGuide DALI-F26x,
LON interface module PCD3.F240
The LON communication modules are described in the manual:
27-636 LON communication module for TP / FT-10 channel
Relevant manual
26-767 LonWorks
®
networks with Saia PCD
®
M-Bus interface module PCD3.F27x
The M-Bus communication modules are described in the manual:
27-603 M-Bus Master Interface Module PCD2.F27x0 and PCD3.F27x
