Optional memory upgrades
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-57
3
3.19.1 Overview
Module
Description
for PCD3.. System DB backup** File system BACnet -IP Slot
PCD7.R500* Flash card module as backup for the
user program.
M5xx0 / M6xx0
(except Mxx6x)
1 MByte
M1 / M2
PCD3.R500* Flash memory module as backup for the
user program.
The module contains a PCD7.R500.
Mxxx0
(except Mxx6x)
1 MByte
I/O Slot 0…3
PCD7.R550M04* Flashcardmodulewithlesystem.Storageofles
e.g.forthewebserver.Thelescanbeaccessedvia
the FTP or HTTP direct server of the PCD3. The Saia
PCD
®
canalsowritePCreadableles(*.csvles)
directly to the module.
M5xx0 M6xx0
4 MByte
M1 / M2
PCD3.R550M04* Flashmemorymodulewithlesystem.Storage
oflese.g.forthewebserver.Thelescanbe
accessed via the FTP or HTTP direct server of the
PCD3. The Saia PCD
®
can also write PC readable
les(*.csvles)directlytothemodule.
The module contains a PCD7.R550M04.
Mxxx0
4 MByte
I/O Slot 0…3
PCD7.R551M04* FlashCardModulewithlesystemandasbackupfor
the user program.
ThelescanbeaccessedviatheFTPortheweb
server of the PCD3. The Saia PCD
®
can also write PC
readableles(*.csvles)directlytothemodule.
M5xx0 M6xx0
1 MByte 3 MByte
M1 / M2
PCD3.R551M04* Flashmemorymodulewithlesystemandasbackup
for the user program.
ThelescanbeaccessedviatheFTPortheweb
server of the PCD3. The Saia PCD
®
can also write PC
readableles(*.csvles)directlytothemodule.
The module contains a PCD7.R551M04.
Mxxx0
1 MByte 3 MByte
I/O Slot 0…3
PCD7.R560* Flash card module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication.
M5xx0,
M6xx0

M1 / M2
PCD3.R560* Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication.
The module contains a PCD7.R560.
Mxxx0

I/O Slot 0…3
