Optional memory upgrades
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-58
3
Module
Description
for PCD3.. System DB backup** File system BACnet -IP Slot
PCD7.R561* Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication,aswell
asalesystem,anditservesasabackupforthe
user program.
M5xx0 ,M6xxx0
with TCP/IP
1 MByte 1 MByte

M1 / M2
PCD3.R561* Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication,aswell
asalesystem,anditservesasabackupforthe
user program.
The module contains a PCD7.R561.
Mxxx0
1 MByte 1 MByte

I/O Slot 0…3
PCD7.R562 Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication,aswell
asalesystem,anditservesasabackupforthe
user program.
M5xx0 ,M6xxx0
with TCP/IP
1 MByte
128 MByte

M1 / M2
PCD3.R562 Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication,aswell
asalesystem,anditservesasabackupforthe
user program.
The module contains a PCD7.R562.
Mxxx0
1 MByte
128 MByte

I/O Slot 0…3
PCD7.R580* Flash memory module with Lon-IP FW. The module
contains both the FW extension for Lon-IP and the
congurationlesfortheLon-IPapplication.
1 MByte

M1 / M2
PCD7.R582 Flash memory module with Lon-IP FW. The module
contains both the FW extension for Lon-IP and the
congurationlesfortheLon-IPapplication,aswell
asa128MBytelesystemandservesasabackup
for the user program.
1 MByte
128 MByte

M1 / M2
PCD3.R582 Flash memory module with BACnet FW. The module
contains both the FW extension for BACnet and the
congurationlesfortheBACnetapplication,aswell
asalesystem,anditservesasabackupforthe
user program.
The module contains a PCD7.R582.
Mxxx0
1 MByte
128 MByte

I/O Slot 0…3
PCD3.R600 BasicmodulefortheSDashmemorycard.Thecard
containsalesystemandservesasabackupforthe
userprogram.ThelescanbeaccessedviatheFTP
or the web server of the PCD3. The Saia PCD
®
can
alsowritePCreadableles(*.csvles)directlytothe
module.
The module can use PCD7.R-SD256 or R-SD512
ashmemorycards.
Mxxx0
1 MByte
to 1 GByte
I/O Slot 0…3
