SBC PCD3 Series User Manual

Saia-Burgess Controls AG
Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
Diagnosis Information of the RIO
RIO (Remote Input Output) head stations
4-8
4
4.4.2 Diagnosis module
In addition to the DP-compliant diagnostic information, the PCD3.RIO also
supportsadiagnosismoduleusedintheDPconguration.Thisslavediagnostic
information is stored in the master resources. The use of a diagnosis module is
notmandatory.Thisdiagnosticmodulemusthoweverbeconguredafterthelast
I/Omodule(exception:plug-insmustbeconguredafter the diagnosis module).
Itrequires4inputbytesand4outputbytes.Theexactdenitionofrequestand
answer is as followed:

Byte 0 Byte 1 Byte 2 Byte3
Query

Byte 0 Byte 1 Byte 2 Byte3
Reply
The contents of bytes 0 to 2 depend on the request command. The master
always checks if the response command matches the request command,
ensuring that the data is correct and belongs to the requested information.
NOP command (command 0)
This command is for synchronization only. The RIO returns the received data
byteswithoutmodication.

Byte 0 Byte 1 Byte 2 Byte3
X Y Z 0

Byte 0 Byte 1 Byte 2 Byte3
X Y Z 0

ThisfunctionreturnsthecurrentrmwareversionoftheRIO.

Byte 0 Byte 1 Byte 2 Byte3
irrelevant irrelevant irrelevant 1

Byte 0 Byte 1 Byte 2 Byte3
highest version lowest version
MSB
lowest version LSB 1
