Saia-Burgess Controls AG

Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29

System overview

PCD3.Mxxx0 Classic CPU and expansion enclosure

3-2

3.1 System overview

PCD3.RIO PCD3.LIO

PCD3.LIOPCD3.CPU

RIO for decentralized tasks

CPU for centralized tasks

SBC-S-Net

3.1.1 SBC S-Net networking concept

SBCS-Netisthenameofthenewexiblenetworkingconceptforinnovativeand

economical automation solutions with SaiaPCD.

BasedontheopenstandardsEthernet-TCP/IP(EtherS-net)andProbus

(ProS-net):Utilizationofexistingnetworkinfrastructure no double ca-

bling required

Supports multivendor and multi-protocol operation:

Reduce costs for project planning, programming, commissioning and mainte-

nancethankstoend-to-enduseofEthernetTCP/IPandProbuswithS-Net

for the Private Control Network (PCN) for SaiaPCD

ConsistentuseofwebtechnologiesviaEthernetTCP/IPandProbusforcom-

missioning, operation, monitoring and diagnostics

IntegratedprogrammingandcommissioningviaEthernetTCP/IPandProbus

IntegratednetworkconnectionsinthebaseunitProbusinterfaceintegratedinthe

operating system of the new PCD3 controllers and PCD3 RIO (included in the

base unit at no extra cost)

Pro-S-Netwithoptimizedprotocolsandservicesforthee󰀩cientoperationof

PCD3RIOandPCD3controllersonProbus

Multi-protocol operation:

ThenewPCD3controllersandPCD3RIOssupportProbus-DPandS-Neton

the same connector

Continuity and investment protection:

AlleSaiaPCDsystemscanbeintegratedintheconceptwiththeexistingPro-

bus and Ethernet TCP / IP connections.
