SBC PCD3 Series User Manual

Saia-Burgess Controls AG
Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
PCD3 CPUs
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-10
3
3.4.3 PCD3.Mxx60
5560
Saia PCD3.M
󰀨
basic devices
Basic Extended

DP
Master
2 ×
Ethernet
PCD3.M 3160 3360 5360 5560 6560 6860
General features
I/O bus extension
-

In-/Outputs or
I/O module slots
to 64
1)
4
to 1023
1) 2)
64
Processor (Freescale ex.
Motorola)
MCF 5373
Processing time
Bit command
word command
0.1…0.8 µs
3)
0.3 µs
3)


Download from the PG5 environment possible
Can be programmed with PG5 from version 2.2.130 from version SP2 2.0.200
Program memory, DB/text
(FLASH)
512 kByte 2 MByte
User memory, DB/text
(RAM)
128 kB 512 kB 1 MByte
Flash memory (S-RIO,

128 MByte
128 MBytes

(INTFLASH)
128 MByte
128 MBytes
Date-clock
accuracy

better than 1 min./month
Data backup
4 hours with Super Cap
(after 10 minutes of
charging time)
Lithium battery Renata CR 2032
1-3 years
4)
Interrupt inputs
max. Input frequency
2
1 kHz
5)
Interfaces
Programming interface USB
6)
Programming interface
(PGU) or
as a serial interface
-
Port 0
RS-232
to 115 kBit/s
Optional,
serial data interfaces
Port 1
RS-232, RS-422/485 or TTY current loop 20mA,
pluggable (PCD3.F1xx modules)
